Building a Chatbot for Field Notes: A Coding Lab for Ecology Students

nnaturalscience

2026-01-28 12:00:00

9 min read

A classroom coding lab to build a chatbot that helps fieldworkers log structured field notes. Step-by-step guide with speech, extraction, and ethics.

Hook: Make field notes easier — and teachable — with a student-built chatbot

Teachers and students struggle with messy, inconsistent field notes, limited classroom time to practice data collection, and paywalled tools that are hard to adapt for lessons. This lab gives you a practical, classroom-ready coding exercise to build a simple chatbot that helps fieldworkers log observations, extract structured data, and produce compact summaries for later analysis. Inspired by 2025–2026 developments tying voice assistants to foundation models (for example, news about Apple pairing Siri with Google's Gemini), the exercise demonstrates safe, curriculum-linked ways to combine voice, local models, and simple natural-language processing in a controlled learning environment.

Why this matters in 2026: trends that shape the lab

By 2026, two trends make this lab timely and transferable to curriculum goals:

Voice + foundation models: Major platforms are linking voice assistants to foundation models, improving contextual responses and on-device reasoning. This trend highlights how conversational interfaces can assist fieldwork by turning speech into structured records (recent reporting referenced Apple using Gemini-like models to extend Siri's capabilities).
On-device and edge AI: Privacy and connectivity constraints in the field are pushing educators to teach offline strategies — lightweight models, local speech-to-text, and robust data syncing. See work on Raspberry Pi inference farms and tiny edge vision models that make field deployments feasible.

Learning objectives (student outcomes)

Design a simple conversational UI to collect field notes via text, speech, and photos.
Implement rule-based and model-assisted methods to extract structured fields from free text.
Understand data privacy, metadata standards, and ethical considerations for ecological data collection.
Practice reproducible data storage and create a small pipeline from input to CSV/JSON for later analysis in computational ecology.

Classroom materials & prerequisites

Target group: upper-secondary or undergraduate ecology/computational ecology students. Time: 2–3 lab sessions (90–180 minutes) or a week-long project.

Basic Python (variables, functions), Jupyter or simple IDE experience.
Computer with internet for initial setup (optional: low-power device for field testing).
Python libraries: pandas, regex, spaCy (optional), gradio or streamlit for UI, speech-recognition or local Whisper for audio transcription, and an optional LLM client (local model or cloud API).
Starter dataset: a few dozen example field notes (you'll find sample CSV at the end).

High-level architecture

The chatbot lab implements a compact pipeline:

User input: text, microphone (speech-to-text), and photo upload.
Preprocessing: cleaning, timestamping, optional GPS.
Extraction: rule-based NLU or prompt-based LLM extraction into fields (species, count, behavior, habitat, observer). Consider lightweight local models or quantized 4–7B options for offline use.
Summarisation & tags: short summary + suggested tags for later search.
Storage: local CSV/JSON with metadata for classroom analysis; design sync logic inspired by edge‑sync/offline-first patterns so notes queue when offline.

Field-note schema (practical)

Use a clear structure so student outputs are analyzable. Example JSON schema:

{
  "id": "uuid",
  "observer": "string",
  "timestamp": "ISO8601",
  "location": {"lat": float, "lon": float, "accuracy_m": int},
  "raw_text": "string",
  "photo_paths": ["path1.jpg"],
  "species": "string",
  "count": int,
  "behavior": "string",
  "habitat": "string",
  "summary": "string",
  "tags": ["tag1","tag2"]
}

Step-by-step coding exercise

Step 0 — Set up the environment

Install required Python packages in a virtual environment. For a low-friction classroom, use a Binder or Google Colab notebook with preinstalled packages, or provide a Dockerfile for local setup.

pip install pandas gradio spacy pandas python-dotenv

Optional for speech and local models:

pip install openai-whisper whisperx torch torchvision

Step 1 — Build a minimal Gradio UI

Gradio simplifies making a web UI for the classroom. The interface lets students type free-text notes, speak via microphone, and upload photos.

import gradio as gr
import pandas as pd
import uuid, datetime

storage = "field_notes.csv"

def save_note(raw_text, photo):
    note = {
        "id": str(uuid.uuid4()),
        "observer": "Student Name",
        "timestamp": datetime.datetime.utcnow().isoformat(),
        "location": "",  # add later
        "raw_text": raw_text,
        "photo_paths": photo.name if photo else "",
        "species": "",
        "count": "",
        "behavior": "",
        "habitat": "",
        "summary": "",
        "tags": ""
    }
    df = pd.DataFrame([note])
    df.to_csv(storage, mode='a', header=not pd.io.common.file_exists(storage), index=False)
    return "Saved: " + note['id']

iface = gr.Interface(fn=save_note, inputs=[gr.Textbox(lines=4), gr.Image(type='filepath')], outputs="text")
iface.launch()

This minimal stub lets students submit raw notes and saves them. Next, make the bot help extract fields.

Step 2 — Rule-based extraction: fast, explainable

Start with deterministic extraction so students can see how NLU works. Use regex and keyword lists to pull counts, species-like capitalized words, and behavior verbs.

import re

SPECIES_LIST = ["sparrow","robin","oak"," buttefly"]  # classroom example
BEHAVIOR_KEYWORDS = ["foraging","flying","nesting","calling"]

def extract_fields(text):
    text_l = text.lower()
    # Count extraction
    m = re.search(r"(\d+) (?:individuals|birds|trees|plants)", text_l)
    count = int(m.group(1)) if m else None
    # Species by keyword
    species = next((s for s in SPECIES_LIST if s in text_l), "")
    # Behavior by keyword
    behavior = next((b for b in BEHAVIOR_KEYWORDS if b in text_l), "")
    return {'species': species, 'count': count, 'behavior': behavior}

Students can extend the keyword lists, test false positives, and discuss limitations of rule-based methods.

Step 3 — Lightweight model-assisted extraction

Once students grasp rule-based limits, introduce a prompt-based extractor using a small, local LLM or a cloud API. Emphasize prompt design and why you might prefer on-device models for field privacy. Example classroom prompt:

"Extract species, count, behavior, and habitat from this observation. Return JSON with keys: species, count, behavior, habitat."

Use a local 7B model or the school's approved API. Show how outputs can be validated against rule-based results and how continual-learning tooling supports iterative improvement and active learning loops.

Step 4 — Add summarisation and tags

Summaries let students quickly scan long notes. For example, generate a one-line summary and three tags. Example function (pseudo-code):

def summarize_and_tag(raw_text, extractor):
    fields = extractor(raw_text)
    summary = f"{fields.get('count','?')} {fields.get('species','unknown')} observed {fields.get('behavior','')}."
    tags = [fields.get('species'), fields.get('behavior'), 'habitat:'+fields.get('habitat','unknown')]
    return summary, tags

Students can compare summaries from rule-based and model-based approaches and measure agreement.

Step 5 — Speech input: linking voice to the model

In the field, speech is faster than typing. For classroom testing, demonstrate two options:

Browser speech-recognition API: simple, no server setup, but requires internet and browser support.
Local Whisper-like transcription: more reproducible and works offline if compute permits. For robust offline tests you can use Raspberry Pi clusters or small inference setups described in community writeups.

Example using Gradio's microphone input (simplified):

def transcribe_and_process(audio):
    # audio is a file; run it through a transcription model or API
    text = run_whisper(audio)  # placeholder
    fields = extract_fields(text)
    summary, tags = summarize_and_tag(text, extract_fields)
    save_to_csv( ... )
    return summary

iface = gr.Interface(fn=transcribe_and_process, inputs=gr.Audio(source='microphone', type='filepath'), outputs='text')

Discuss tradeoffs: transcription accuracy in noisy field sites, battery and compute cost, and the risks of over-relying on transcription for scientific records. Refer to discussions of on-device AI strategies when weighing privacy vs cloud transcription.

Data quality, ethics, and curriculum alignment

Integrate this lab with assessment criteria:

Accuracy: How often do extracted fields match a human-labeled ground truth?
Reproducibility: Students must version their code, data, and prompts. Encourage micro‑app development practices from tutorials on building small, reproducible apps (micro‑app examples).
Privacy and consent: Teach students to strip human-identifiable data, protect GPS fidelity (round coordinates when needed), and obtain consent for audio/photo records — align with guidance on safety & consent for voice data.
Metadata & standards: Map outputs to biodiversity standards like Darwin Core if you plan to share data externally (GBIF-compatible fields).

Practical classroom assessment tasks

Task: Collect 30 short observations. Compare rule-based vs. model-assisted extraction accuracy, report precision/recall for species and count.
Extension: Build a classifier that flags low-confidence extractions for human review (active learning loop) — see resources on continual learning and tooling.
Cross-curricular: Map collected locations in QGIS and calculate species richness per plot.

Troubleshooting and common pitfalls

Low transcription quality: test with a range of voices and background noise; add prompts that guide speakers to include key fields (e.g., "State species, number, behavior").
Overfitting keyword lists: teach students to test on unseen notes and maintain a holdout set.
Model hallucination: when using LLMs, check for invented species — always keep a verification step before publishing data.
Connectivity issues: provide an offline mode that caches notes and syncs when back online; study offline-first patterns for reliable sync.

Advanced extensions for computational ecology students

Deploy a small on-device model (e.g., a quantized 4–7B model) for offline extraction and summarization; discuss tradeoffs in latency, battery, and accuracy and investigate Raspberry Pi deployment writeups (Raspberry Pi clusters).
Integrate automated metadata enrichment (reverse-geocoding, habitat classification using photo + computer vision); test tiny edge vision models like AuroraLite for photo-based features.
Set up federated or privacy-preserving aggregation so student devices contribute anonymized statistics without sharing raw audio.
Link outputs to national biodiversity repositories (GBIF/OBIS) after curation.

Why discuss Siri + Gemini in the lab?

News in late 2025 and early 2026 about major voice assistants connecting to foundation models underlines the real-world direction of conversational field tools: better context awareness, cross-app integration (e.g., photos and calendar), and personalized assistance. Use this as a teaching moment to compare centralized foundation-model services with classroom-safe local solutions. Students should learn when to use each approach and how to protect data when using commercial services. See practical notes on privacy-conscious voice handling in safety & consent guidance.

“Apple’s move to adopt advanced foundation models for Siri highlights how conversational interfaces can become powerful data-capture tools — but only when coupled with clear privacy and validation practices.”

Example starter dataset (classroom-use)

Provide students with ~50 synthetic observations to test extractors. Each row: raw_text, photo_example, lat, lon, observer. Encourage students to hand-label 10–15 rows for evaluation.

Actionable checklist for teachers (ready to use)

Prepare the environment (Colab/Binder/Docker) and preinstall libraries.
Introduce the problem: real messy field notes and why structure matters.
Walk through minimum viable bot: Gradio interface + save to CSV.
Run rule-based extraction, discuss failures, iterate lists.
Introduce prompt-based or local model extraction; compare results and try building a small micro-app or demo following micro-app guides.
Highlight ethics and metadata mapping to Darwin Core.
Assign assessment: evaluate extraction performance and map results in QGIS.

Assessment rubrics and learning artifacts

Grade on reproducibility (20%), extraction accuracy (30%), code quality and documentation (25%), and ethical considerations and metadata (25%). Require a short lab writeup plus a recorded demonstration of the bot collecting three field notes.

Resources & references (2025–2026 context)

Key topical points for classroom discussion:

News about voice assistants integrating foundation models (Apple/Siri and Gemini reporting in late 2025).
Advances in lightweight on-device LLMs and quantized models in 2025–2026 enabling offline use — plus community notes on deploying tiny vision models like AuroraLite.
Biodiversity data standards: Darwin Core and GBIF submission guidelines for when curated data is ready to share.

Final practical takeaways

Start simple: rule-based extraction teaches core concepts and is explainable for students.
Layer intelligence: add prompt-based or small LLM extraction once students understand limitations; support model improvement with continual learning tools.
Protect privacy: prefer local transcription and anonymize GPS before sharing; follow safety & consent best practices.
Institutionalize curation: always include a human verification step before adding records to scientific repositories.

Call to action

Ready to run this lab? Download the starter Jupyter notebook and Gradio demo from our educational repository, test the rule-based extractor with your class, and share the student projects with the community. Try a two-week mini-project: collect, curate, and map 100 classroom field notes, then present findings on species occurrence and data quality. Share your results and adaptations — we'll publish exemplary student projects and lesson plans to help other teachers. Sign up for the NaturalScience teaching pack to get the starter code, synthetic dataset, and assessment rubric.
